Ubiquiti USW-WAN-RJ45 UniFi WAN Switch RJ45
Model#: USW-WAN-RJ45
Sku: IT6203
MSRP: $309.99
In Stock
Your Price: $309.99
MODEL: USW-WAN-RJ45
UniFi WAN Switch RJ45
10 GbE WAN Switch linking two Shadow Mode High Availability UniFi Gateways to a single ISP.
Features:
- Combine with Shadow Mode High Availability to ensure uninterrupted connectivity
- (1) 10 GbE ISP uplink and (2) 10 GbE downlink ports
- (2) AC inputs for power redundancy
- (1) GbE port for management with UniFi Network
Specifications USW-WAN-RJ45
| Dimensions | 442.4 x 120 x 43.7 mm(17.4 x 4.72 x 1.7") |
| Port Layout | |
| 1 GbE RJ45 | 1 (1G/100M/10M) |
| 10 GbE RJ45 | 3 (10G/5G/2.5G/1G/100M) |
| Redundancy | (2) AC inputs |
| Form Factor | Rack mount (1U) |
| Performance | |
| Switching Capacity | 20 Gbps |
| Total Non-Blocking Throughput | 10 Gbps |
| Forwarding Rate | 15 Mpps |
| Hardware | |
| Max. Power Consumption | 18W |
| Power Method | (2) Universal input, 100—240V AC, 50/60 Hz |
| Power Input Method | AC input |
| Power Supply | (2) AC/DC, internal, 36W |
| Supported Voltage Range | 100—240V AC |
| Management | Ethernet |
| Weight | Without mounting brackets: 2.3 kg (5.1 lb) With mounting brackets: 2.4 kg (5.3 lb) |
| Enclosure Material | SGCC steel |
| Mount Material | SGCC steel |
| ESD/EMP Protection | Air: ± 16kV, contact: ± 10kV |
| Ambient Operating Temperature | -5 to 40° C (23 to 104° F) |
| Ambient Operating Humidity | 10 to 90% noncondensing |
| LEDs | |
| Ethernet | Yes |
| System | Yes |
| Certifications | CE, FCC, IC |
| NDAA Compliant | Yes |
| Software | Application Requirements |
| UniFi Network | Version 9.1.119 and later |
