RB5009UG+S+IN

Mikrotik


Mikrotik Routerboard RB5009UG+S+IN 10GBPS 1.4GHZ L5


Model#: RB5009UG+S+IN

Sku: IT6197



MSRP: $229.99

In Stock

Your Price: $229.99






MODEL: RB5009UG+S+IN

RouterBORD 5009UG+S+ with Marvell Armada ARMv8 CPU (4-cores, 1.4GHz per core), 1GB of DDR4 RAM, 1GB NAND storage, 1x 2.5Gbit LAN, 7x 1Gbit LAN, 1xSFP+ port, RouterOS L5, metal desktop case, PSU

We took your feedback from the MikroTik User Meetings to create the perfect home lab router: compact, powerful, with multiple powering options and efficient cooling. RB5009 has it all, and even more!

Unprecedented processing power in such a small form factor. Boards come with 1GB of DDR4 RAM and 1GB NAND storage. This combination of ports and components, compared to our other products in a similar form factor, provides almost double the performance in configurations with heavy CPU loads. The board features 9 wired ports and a full-sized USB 3.0. Seven of the ports are Gigabit Ethernet, another one is 2.5 Gigabit Ethernet, and the last one is a 10G SFP+ cage. All the ports are connected to a powerful Marvell Amethyst family switch-chip with a 10 Gbps full-duplex line leading to the Marvell Armada Quad-core ARMv8 1.4 GHz CPU. Both CPU and the switch-chip are located on the bottom of the board – so the case acts as a massive heat-sink!

Boards come with 1GB of DDR4 RAM and 1GB NAND storage. This combination of ports and components, compared to our other products in a similar form factor, provides almost double the performance in configurations with heavy CPU loads.

With a simple set of mounting accessories, you can mount FOUR of these routers in a single 1U rackmount space! No more server-room-Tetris, just pure productivity.

RB5009UG+S+IN can be powered in 3 different ways:

  • a) PoE-in from Ethernet port #1
  • b) DC Jack
  • c) 2-pin terminal on the side

Features:

  • 7x Gigabit Ethernet ports
  • 1x 2.5 Gigabit Ethernet port
  • 10G SFP+
  • Durable metallic case
  • Powerful quad-core CPU
  • 1 GB DDR4 RAM
  • 1 GB NAND
  • RouterOS v7
  • Multiple powering options

Specifications RB5009UG+S+IN

CPU 88F7040 1.4 GHz
CPU architecture ARM 64bit
CPU core count 4
Size of RAM 1 GB
RAM type DDR4
Storage 1 GB, NAND
Number of 1G Ethernet ports 7
Number of 2.5G Ethernet ports 1
Number of 10G SFP+ ports 1
USB port 1 (3.0 type A)
Operating system RouterOS (License level 5)
Switch chip model 88E6393
Dimensions 220 x 125 x 22 mm (8.66" x 4.92" x 0.86" in)
Operating temperature -40°C to +60°C
Powering
PoE-in 802.3af/at
Number of DC inputs 3
Supported input voltage 24-57 V (PoE in) 24-57 V (DC jack) 24-57 (2-pin terminal)
Power adapter nominal voltage 24 V
Power adapter nominal current 1.5 A
Max power consumption (without attachments) 14 W
Max power consumption 20 W
Certification CE, FCC, IC

Datasheet

PDF File Mikrotik Routerboard RB5009UG+S+IN 10GBPS 1.4GHZ L5
