SXTR&FG621-EA
SXTR&FG621-EA picture 3

Mikrotik


MikroTik SXT LTE6 kit (RouterOS L3) with FG621-EA card, International Version


Model#: SXTR&FG621-EA

Sku: IT6159



MSRP: $129.99

In Stock

Your Price: $129.99






MODEL: SXTR&FG621-EA

SXT LTE6 kit (RouterOS L3) with FG621-EA card, International Version

SXT LTE6 kit is an update of our timeless device for remote locations that are within cellular network coverage. It features the same modern Category 6 LTE chip that you might have seen in our latest devices – like the popular Chateau LTE6 ax! Not only this LTE chip can provide reliable Internet connectivity for your building even where cell phones fail, it also allowed us to drive the price for this kit way down. Mount an SXT outside your home – and always stay connected!

You’re getting the classic, fundamental design that has stood the test of time. Weatherproof. Unobtrusive. Snow-resistant. With a modern LTE6 card for uninterrupted mobile connectivity. And a price around 30% lower than the original SXT LTE6 kit. Furthermore, we offer significant project discounts and custom branding options on volume orders. The best price on the market becomes even better!

We’ve included two Micro-SIM slots – for backup. It never hurts to have extra options when it comes to mobile network coverage. Also, the Category 6 LTE modem enables carrier aggregation, allowing SXT to use multiple LTE bands simultaneously. That’s a huge advantage when there are a lot of mobile users in the area. It offers better responsiveness in a crowded environment. And higher efficiency for weaker signal situations in the countryside. Win-win! We have seen Internet speed doubling in rural areas after switching to CAT6, so there is no need to wait for cable network expansions.

The unit is equipped with two Ethernet ports and PoE functionality: PoE-in on Ether1, PoE-out on Ether2. That means SXT can power other devices or be powered by other devices, making your cable management so much easier! Unit is shipped with a 24 V power supply, but can support a wide range of 12-57 V and is 802.3af/at compliant.

Specifications SXTR&FG621-EA

CPU QCA9531 650 MHz
CPU architecture MIPSBE
CPU core count 1
Size of RAM 64 MB
RAM type DDR2
Storage 16 MB, Flash
Number of 100M Ethernet ports 2
MiniPCIe slots 1
LTE category 6 (300Mbit/s Downlink, 50Mbit/s Uplink)
LTE modem R11eL-FG621-EA
TAC 86335904
LTE FDD bands 1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 7 (2600MHz) / 8 (900MHz) / 20 (800 MHz) / 28 (700MHz)
LTE TDD bands 38 (2600MHz) / 40 (2300MHz) / 41 (2500MHz)
MIMO DL 2x2
MIMO UL 1x1
3G Category R8 (42.2Mbps Downlink, 11.2Mbps Uplink)
3G Bands 1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 8 (900MHz)
Dimensions

140 x 140 x 56 mm

5.51 x 5.51 x 2.20 inch

Operating system RouterOS v7, License level 3
Operating temparature -40°C to +60°C
Powering
Number of DC inputs 1
PoE-in Yes, on Ether1
PoE-Out Yes on Ether2, max out per port output (input < 30 V): 600 mA, max out per port output (input > 30 V): 400 mA
Supported input voltage 12-57 V (Passive PoE 802.3af/at on Ether1)
Power adapter nominal voltage 24 V
Power adapter nominal current 1.2 A
Max power consumption without attachments 5 W
Max power consumption 22 W
Supported 2xCA LTE bands
1+1/3/5/7/8/20/28 40+40
3+3/5/7/8/20/28 8+8
5+5/7 38+38
7+7/8/20/28 41+41

Datasheet

PDF File MikroTik SXT LTE6 kit (RouterOS L3) with FG621-EA card, International Version
