DIMENSIONS:

• Width x Height x Depth:
  442.4 x 43.7 x 285.6 mm
  (17.42 x 1.72 x 11.24")
• Weight: 3.90 kg (8.60 lb)
• With Mounting Kits:
  3.99 kg (8.80 lb)

Interfaces

• (8) 10/100/1000 RJ45 LAN Ports
• (1) 10/100/1000 RJ45 WAN Port
• (1) 1/10G SFP+ LAN Port
• (1) 1/10G SFP+ WAN Port

Management Interfaces

• Ethernet In-Band
• (1) Bluetooth BLE

Technical Information

• IDS/IPS Throughput: 3.5 Gbps *
• Processor: Quad ARM Cortex-A57 Core at 1.7 GHz
• System Memory: 4 GB DDR4
• On-Board Flash Storage: 16 GB eMMC
• * Measured with iPerf3.

Environment

• Operating Temperature: -10° to 40° C (14° to 104° F)
• Operating Humidity: 5 to 95% Noncondensing

Power

• Max. Power Consumption: 33W
• Voltage Range: 100 to 240VAC
• Power Method: (1) Universal AC Input, 100-240VAC, 50/60 Hz
• Redundant Power: (1) RPS DC Input
• Power Supply: Internal 50W/12V
• ESD/EMP Protection: Air: ± 16 kV, Contact: ± 12 kV

Certifications

• CE, FCC, IC

PACKAGE CONTENTS

• (2) Rackmount Brackets
• (8) Bracket Screws
• (4) Mounting Screws
• (4) Cage Nuts
• (1) Security Screw
• (4) 2.5" HDD Screws
• Power Cord
• (4) Rubber Feet
