Model: UNVR
UniFi Protect Network Video Recorder
Enterprise network video recorder, can provide up to 30 days of 4K video storage for 15 cameras or Full HD video storage for 50 cameras
The UniFi® NVR is an enterprise network video recorder that integrates an NVR, the UniFi Protect software, and a 4-drive bay. UNVR unifies enterprise-class data protection and scalable storage with simple Plug and Play integration using the intuitive UniFi Protect software. From a desktop computer or mobile device, you can access your surveillance recordings from virtually anywhere using the intuitive graphical user interface. The mobile app is available for iOS and Android-based devices. The drive bays are easily accessed from the front panel, so hard drive mounting and maintenance are simple. Using four 8 TB drives in a RAID 5 configuration, the UNVR can provide up to 30 days of 4k video storage for 15 cameras or Full HD video storage for 50 cameras.
Features:
- (4) 2.5"/3.5" Drive bays
- (1) 10G SFP+ port
- (1) Gigabit RJ45 port
- 1U rackmountable (kit included)
- Plug and Play UniFi Protect system with NVR
- Automated secure RAID 1 or RAID 5 configuration
- Supports USP-RPS for PSU failover
-
Store your footage for 30 days
Enterprise network video recorder, can provide up to 30 days of 4K video storage for 15 cameras or Full HD video storage for 50 cameras
Proprietary redundant power system designed to protect from sudden power supply module failure.
-
Automized Secure RAID1/5 Configuration
The UNVR unifies enterprise-class data protection and scalable storage with simple Plug and Play integration using the intuitive UniFi Protect software.
Model: UNVR
- Dimensions: 442.4 x 325 x 43.7 mm (17.4 x 12.8 x 1.7")
- Weight Without Rackmount Brackets: 5.11 kg (11.27 lb)
- Weight With Rackmount Brackets: 5.20 kg (11.46 lb)
- Enclosure Characteristics: SGCC Steel
- Processor: Quad-Core ARM Cortex-A57 at 1.7 GHz
- System Memory: 4 GB DDR4
- On-Board Flash Storage: SPI NOR 32 MB, USB Flash 8 GB
- Max. Power Consumption: 100W
- Max. Power Budget for Drives: 75W
- Power Method: (1) Universal AC Input (1) RPS DC Input
- Power Supply: 100-240VAC, 50/60 Hz, 2A
- Networking Interfaces: (1) 10/100/1000 Mbps RJ45 Ethernet (1) 1/10 Gbps SFP+ Ethernet
- Management Interface: Ethernet In-Band Management
- ESD/EMP Protection: Air: ± 12kV, Contact: ± 8kV
- Operating Temperature: -5 to 40° C (23 to 104° F)
- Operating Humidity: 5 - 95% Noncondensing
Datasheet
