SXTsq 5 ac-US

Mikrotik


MikroTik SXTsq 5 ac (RBSXTsqG-5acD-US) 5GHz SXT 16dBi 802.11ac PoE PSU L3 US



Product Highlights
  • The SXTsq 5 ac also known as RBSXTsqG-5acD is a compact and lightweight outdoor 5Ghz 802.11ac wireless device with an integrated antenna, perfect for point-to-point links or as a CPE unit
  • The device includes one 10/100/1000 Mbit Ethernet port to fully utilize speeds that 802.11ac protocol provides
  • The SXTsq 5 ac retains a 16 dBi antenna. The antenna design has been improved and the physical size has been dramatically reduced - the SXTsq is two times thinner
  • Dimensions: 129 x 129 x 34 mm, Size of RAM: 256 MB, Storage size: 16 MB, PoE in: Passive PoE, PoE in input Voltage: 10-28 V
  • Wireless 5 GHz number of chains: 2, Wireless 5 GHz standards: 802.11a/n/ac, Antenna gain dBi for 5 GHz: 16, 10/100/1000 Ethernet ports: 1
  • Model#: SXTsq 5 ac-US

    Sku: IT2514



    MSRP: $69.99


    Out of stock

    Your Price: $69.99


    MODEL: SXTsq 5 ac (RBSXTsqG-5acD) US VERSION

    Low-cost small-size 16dBi 5GHz dual chain integrated CPE/Backbone with AC support and Gigabit Ethernet

    The SXTsq 5 ac is a compact and lightweight outdoor 5Ghz 802.11ac wireless device with an integrated antenna, perfect for point-to-point links or as a CPE unit. The device includes one 10/100/1000 Mbit Ethernet port to fully utilize speeds that 802.11ac protocol provides.

    The SXTsq 5 ac retains a 16 dBi antenna like the SXT 5 ac, our previous model, yet the antenna design has been improved and the physical size has been dramatically reduced - the SXTsq is two times thinner.

    - SXTsq 5 ac-US (USA) is factory locked for 5170-5250MHz and 5725-5835MHz frequencies. This lock can not be removed.

    Specifications

    Details
    Product code RBSXTsqG-5acD
    Architecture ARM 32bit
    CPU IPQ-4018
    CPU core count 4
    CPU nominal frequency 716 MHz
    Dimensions 129 x 129 x 34 mm
    RouterOS license 3
    Operating System
    Size of RAM 256 MB
    Storage size 16 MB
    Storage type FLASH
    MTBF Approximately 100'000 hours at 25C
    Tested ambient temperature -40°C to 70°C
    IPsec hardware acceleration Yes


    Powering

    Details
    Number of DC inputs 1 (PoE-IN)
    Max power consumption 7 W
    Cooling type Passive
    PoE in Passive PoE
    PoE in input Voltage 10-28 V

    Wireless specifications

    Details
    Wireless 5 GHz Max data rate 867 Mbit/s
    Wireless 5 GHz number of chains 2
    Wireless 5 GHz standards 802.11a/n/ac
    Antenna gain dBi for 5 GHz 16
    Wireless 5 GHz chip model IPQ-4018
    Wireless 5 GHz generation Wi-Fi 5

    Ethernet

    Details
    10/100/1000 Ethernet ports 1

    Certification & Approvals

    Details
    Certification CE, FCC, IC, EAC, ROHS
    IP IP54

    Wireless specifications

    5 GHz Transmit (dBm) Receive Sensitivity
    6MBit/s 25 -96
    54MBit/s 21 -80
    MCS0 25 -96
    MCS7 20 -75
    MCS9 18 -70

    Included parts

    The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..


    Datasheet

    PDF File MikroTik SXTsq 5 ac (RBSXTsqG-5acD-US) 5GHz SXT 16dBi 802.11ac PoE PSU L3 US
