Ubiquiti Networks UAP-XG-US UniFi AP XG US

Product Highlights
  • (2) 5 GHz (4x4 MU-MIMO) radios
  • 3.466 Gbps aggregate throughput rate over the 5 GHz band
  • 2.4 GHz (4x4 MIMO) band with a 800 Mbps throughput rate
  • 1,500-client limit
  • Powered by PoE++ (PoE injector included)
  • Model#: UAP-XG-US

    Sku: IT2018

    MSRP: $819.99

    In Stock

    Your Price: $819.99

    Model: UAP-XG-US

    UniFi XG Access Point 5GHz 802.11ac

    Expand your 10-Gigabit network with the UniFi XG Access Point, part of the Ubiquiti Networks UniFi Enterprise Wi-Fi System.

    Deploy the UniFi XG AP in very high-density environments requiring maximum wireless performance. The UniFi XG AP features simultaneous, dual-band, 4x4 MU-MIMO technology and convenient 802.3bt PoE compatibility. Available in single- and five.packs.

    Quad-Radio Capabilities: Three client radios deliver unparalleled Wi-Fi performance while a dedicated security radio provides persistent threat management.

    Superior Processing Power: The UniFi XG AP is capable of complex operations (guest control, filtering, and other resource-intensive tasks) that may slow down a lesser equipped AP.

    10G and 1G Ethernet Connectivity: Designed to be a 10G Ethernet backhaul, the primary port carries both data and PoE, while the secondary Gigabit Ethernet port is for bridging and also supports PoE input.

    Power over Ethernet (PoE) Standard: The UniFi XG AP can be powered by an 802.3bt PoE compliant switch.

    Easy Mounting: Its sleek design seamlessly integrates into any environment (all accessories included) and is compatible with existing UAP-AC-PRO mounts.

    LED: The unique LED provisioning ring provides administrator location tracking and alerts for each device.



    • 10Gigabit Ethernet Support
    • 4x4 MU-MIMO Quad-Radio: (3) client, 1 Security
    • Dual 5 GHz 802.11ac Wave 2 Radios
    • 3.466 Gbps Combined Radio Rate in 5 GHz
    • 800 Mbps Radio Rate in 2.4 GHz
    • Dedicated Security Radio with Persistent Threat Management
    • 1,500 Client Association Limit
    • 802.3bt Power Injector Included

    Specifications UAP-XG-US

    Dimensions      228 x 228 x 50 mm
    (8.98 x 8.98 x 1.97")
    WithMounting Kits
    1.20 kg (2.65 lb)
    1.35 kg (2.98 lb)
    Networking Interface (1) 10/100/1000 Ethernet Port (1) 1/10 Gbps ICM Ethernet Port
    Buttons Reset
    Power  Method 802.3bt PoE
    Supported Voltage Range 44 to 57VDC
    Power Supply PoE Injector 50VDC, 1.2A Gigabit
    Power Save Supported
    Maximum Power Consumption 31W
    Radios 2.4 GHz, (2) 5 GHz, Security
    Maximum TX Power 2.4 GHz 5 GHz 25 dBm 25 dBm
    Antennas 2.4 GHz 5 GHz (2) Dual-Port, Dual-Polarity Antennas, 6 dBi each (2) Dual-Port, Dual-Polarity Antennas, 8 dBi each
    Wi-Fi Standards 802.11 a/b/g/n/ac/ac-wave2
    Wireless Security WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES), 802.11 w/PMF
    BSSID Up to 8 per Radio
    Mounting Wall/Ceiling/Junction Box (Kits Included)
    Operating Temperature -10 to 60° C (14 to 140° F)
    Operating Humidity 5 to 95% Noncondensing
    Certifications CE, FCC, IC
    Advanced Traffic Management
    VLAN 802.1Q
    Advanced QoS Per-User Rate Limiting
    Guest Traffic Isolation Supported
    WMM Voice, Video, Best Effort, and Background
    Concurrent Clients 1500
    Supported Data Rates (Mbps)
    Standard Data Rates
    802.11ac 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80)
    802.11n 6.5 Mbps to 450 Mbps (MCS0 - MCS23, HT 20/40)
    802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
    802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
    802.11b 1, 2, 5.5, 11 Mbps
