UAP-AC-M

Ubiquiti


Ubiquiti Networks UniFi Mesh AC AP UAP-AC-M Wide-Area Indoor/Outdoor Dual-Band Access Point


Model#: UAP-AC-M

Sku: IT1800



MSRP: $99.00


Out of stock

Model: UAP-AC-M

                                          UniFi AC Mesh

                              802.11AC Indoor/Outdoor Wi-Fi Access Point

The Ubiquiti UAP-AC-M is an 802.11 mesh access point. With mesh multi-hop, you can can cover a large outdoor area with minimal infrastructure, with just a few mesh access points. These APs include adjustable dual-band omnidirectional antennas, but can be used with any 5 GHz omni antenna for spot-beam coverage in high-density locations with numerous APs and clients. These models are great for temporary installations, with quick setup and takedown, ideal for music festivals and concert venues.

  • Antenna Versatility

Adjustable dual-band omni-directional antennas and Fast-Mount included for expanded range coverage. Simultaneous Dual Band 2x2 MIMO

  • Optimal Performance

Dual-Band performance with aggregate speeds of up to 1167 Mbps.

  • Compact Form Factor

The UniFi AC Mesh base is just slightly larger than a standard pen, making it easy to deploy anywhere. Dimensions: 354 x 46 x 34 mm (H x W x D).

  • Multiple Power Options

Power the UniFi AC Mesh with an 802.3af compatible switch, a UniFi PoE Switch, or the included Gigabit PoE adapter.

Product Specifications
• Dimensions: 353 x 46 x 34.4 mm (13.9 x 1.81 x 1.35 ")
• Weight: 152 g (5.36 oz) with Antennas
• Networking Interface: (1) 10/100/1000 Ethernet Port
• Power Method:
    24V Passive PoE (Pairs 4, 5+; 7,8 Return)
    802.3af Alternative A (Pairs 1, 2+; 3,6 Return)
    (Supported Voltage Range: 44 to 57 VDC)
• Power Supply: 24V, 0.5A Gigabit PoE Adapter (Included)
• Power Save: Supported
• Maximum Power Consumption: 8.5 W
• Maximum TX Power:
    2.4 GHz: 20 dBm
    5 GHz: 20 dBm
• Antennas: (2) External Dual-Band Omni Antennas
    2.4 GHz: 3 dBi
    5 GHz: 4 dBi
• Wi-Fi Standards: 802.11 a/b/g/n/ac
• Wireless Security: WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
• BSSID: Up to Four per Radio
• Mounting: Wall/Pole/Fast-Mount (Kits Included)
• Operating Temperature: -30 to 70°C (-22 to 158°F)
• Operating Humidity: 5 to 95% non-condensing
• Certifications: CE, FCC, IC

Advanced Traffic Management
• VLAN: 802.1Q
• Advanced QoS: Per-User Rate Limiting
• Guest Traffic Isolation: Supported
• WMM: Voice, Video, Best Effort, and Background
• Concurrent Clients: 200+

Supported Data Rates (Mbps)
• 802.11ac: 6.5 to 867 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80)
• 802.11n: 6.5 to 300 Mbps (MCS0 - MCS15, HT 20/40)
• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11b: 1, 2, 5.5, 11 Mbps
